RadioLink AT10 II SPECIFICATIONS

new: AT10 II 2.4Ghz 12CH

name: Hanma Store

Recommend Age: 12+y

Origin: Mainland China

Model Number: RadioLink AT10 II

Material: Metal

Brand Name: abay

Features:

Multiple function remote control system.including helicopter.airplane and slider three type flying machine and five models.cover almost every popular model.you can fly any model by this radio.

3.5 inch colorful screen 320×480 resolution.clear display menu and graphs.
Great control distance: 1.1km on the ground.2km in the sky.
Expansion feedback module.users can get plane details in real time.
Make very setting clear and exactly output result.
Fast response time only 3ms to the operation.faster then the other transmitter 20ms.even ten channels also let you feel it.
High channel resolution reaches 4096.0.25us per resolution let all the servos keep tranquil.
Strong anti-jumping.DSSS(Direct sequence spread spectrum) technology.
Unbelievable price. high quality as supper bland. and more exactly. faster response. higher resolution.one and the only one anti-jumping DSSS technology.really worthy to have it.


Technical Parameter:

1.Frequency: 2.4GHz ISM band (2400MHz~2485MHz);

2.Modulation mode: QSPK

3.Channel bandwidth: 5.0MHz

4.Spread spectrum: DSSS

5.Adjacent channel rejection: >38dBM

6.Transmitter power: <100mW(PCB testing);<20dBm(3 meter air testing)

7.Operating Voltage: 8.6~15V

8.Operating Current: <95mA

9.Control distance: 800 meters ground

10.Channel:  12Channel. 5~12 channel are customizable

11.Compatible model: Include all 120 degree and 90 degree swashplate helicopter.all fix wing and glider.five flying model

12.Simulator model: under the simulator



Specifications:

Package size: 33 * 26 * 12cm / 13 * 10.2 * 4.7in
Package weight: 1276g / 2.8lb



Package list:

1 * RadioLink AT10 II 12CH Transimitter
1 * R12DS 12Ch Receiver
1 * PRM-01 Voltage Return Module
1 * 4Pin Connector
1 * English Manual

Notice: Mode 2 ( left hand Throttle). Mode 1( right hand Throttle)

2.4GHz ISM band (2400MHz to 2483.5MHz) Channel bandwidth: 5.0 MHz Spread spectrum: DSSS&FHSS Adjacent channel rejection: >38dbm Compatible model: include all 120 degree and 90 degree swash-plate helicopter .

The DBI high-gain transmitter antenna allows for controlled distance up to 4km. featuring dual antennas in the receiver (OAL).

This transmitter features a mix mode combining DSSS (Direct Sequence Spread Spectrum) and FHSS (Frequency Hopping Spread Spectrum). with 12 channels. 4 anti-plug functions for real-time telemetry. a response time of just 3 milliseconds. dual antennas controlled by AKM (Advanced Kinematics Module) for an extended range. Additionally. it supports S-BUS. PPM. and PWM protocols.

Enhance your control distance with the new version of RadioLink AT10 II (after November 1. 2016). reaching up to kilometers; this product offers a brand-new choice for professional aerial drones. agricultural drones. and industrial drones.

The PGDS. S.Bus. PPM. and PWM signals can work simultaneously. and this RadioLink AT10 II transmitter is compatible with all types of flight controllers. including Radiolink R-GlSH. Additionally. the AT10 II comes with a receiver module (RGDSM) suitable for use in quadcopters and fixed-wing aircraft.

Real-time data telemetry from the transmitter to the receiver (R12DS) provides monitoring of signal strength. receiver voltage. speed (0-8v). GPS data. and extended engine voltage telemetry module PRM-01.

TWO VE CHANNELS TRANSMITTER FULL TYPES AND FUNCTIONS Suit for all airplanes including helicopter swash plate modes . with USB port can upgrade t0 12 channels just by upgrade firmware .

The RadioLink AT10 II transmitter has an output signal frequency of 12 channels with PWM. specifically 84u5. while its regular jitter is maintained at 1.84u5. which represents only one-quarter of the typical jitter levels found in competing products.

The Anti-Polarity Connect Protection feature in the Intelligent Transmitter (TX) ensures that the device prevents short circuits. even if the plug is inserted incorrectly - meaning that it will not damage the system if connected with the wrong polarity.

The RadioLink AT10 II features programmable mix control. allowing for customization of up to 12 channels with a PHIX6 curve. The menu system offers basic and advanced views. enabling users to tailor throttle and servo curves to their specific needs.

Upgrades via USB cable ensure that the RadioLink AT10 II transmitter always stays current with the latest systems and programs. providing seamless connectivity.
